Product Advantages
Smart Adaptability
Real-time monitoring of server temperature and humidity, with AI load point-to-point and cabinet-to-cabinet intelligent adaptive cooling mode.
Low Initial Investment Cost
Smart cabinet air conditioners eliminate the need for preliminary data center renovation, reducing construction costs.
High Efficiency and Low PUE
Smart cabinet air conditioners, when combined with server cabinets to form a closed space, shorten air distribution distance, minimize cooling loss, and reduce energy consumption.
High Precision
High-quality DC inverter compressors operate over a wide range and respond quickly to load changes for precise cooling.
Electronic expansion valve flow control ensures stable cooling output with high precision, seamlessly matching compressor capacity changes.
EC fans allow adjustable airflow to meet demand.
Flexible Layout and Strong Scalability
Smart cabinet air conditioners can be flexibly placed, supporting both in-cabinet and out-of-cabinet cooling to meet various environmental requirements.
Main Unit Specifications
| Smart Cabinet Type | KM135HLUEY-R-H | KM170HLUEY-R-H | KM1125HLUEY-R-H | KM175TLYEY-R-H | KM1125TLLYEY-R-H | KM1125TLYEY-R-H |
| Refrigerant | R410A | R410A | R410A | R410A | R410A | R410A |
| Cooling Capacity |
|
|
|
|
|
|
| Total Cooling Capacity | 0.9 ~ 3.5 kW | 2.25 ~ 7.5 kW | 3.75 ~ 12.5 kW | 2.25 ~ 7.5 kW | 3.75 ~ 12.5 kW | 3.75 ~ 12.5 kW |
| Sensible Cooling | 0.9 ~ 3.5 kW | 2.25 ~ 7.5 kW | 3.75 ~ 12.5 kW | 2.25 ~ 7.5 kW | 3.75 ~ 12.5 kW | 3.75 ~ 12.5 kW |
| Compressor |
|
|
|
|
|
|
| Standard Quantity | 1 | 1 | 1 | 1 | 1 | 1 |
| Rated Current | 4.32 A | 9.05 A | 15.05 A | 9.05 A | 15.05 A | 15.05 A |
| Fan |
|
|
|
|
|
|
| Quantity | 1 | 4 | 4 | 2 | 3 | 3 |
| Airflow | 800 m³/h | 1700 m³/h | 2700 m³/h | 1700 m³/h | 2700 m³/h | 2700 m³/h |
| Dimensions and Weight |
|
|
|
|
|
|
| Length | 800 mm | 800 mm | 800 mm | 1200 mm | 1200 mm | 1200 mm |
| Width (Depth) | 442 mm | 442 mm | 442 mm | 300 mm | 300 mm | 300 mm |
| Height | 264 mm | 442 mm | 442 mm | 2000 mm | 2000 mm | 2000 mm |
| Weight | 26 kg | 55 kg | 60 kg | 150 kg | 170 kg | 170 kg |
| Electrical Parameters |
|
|
|
|
|
|
| Power Supply | 220V-50Hz-1F+N+PE | 220V-50Hz-1F+N+PE | 220V-50Hz-1F+N+PE | 220V-50Hz-1F+N+PE | 220V-50Hz-1F+N+PE | 220V-50Hz-1F+N+PE |
| Standard Outdoor Unit |
|
|
|
|
|
|
| Model | SCW6 | SCW12 | SCW14 | RCL13A | RCL16A | RCL16A |
Notes
-
Compressor Location: For rack-mounted air conditioners, the compressor is located in the outdoor unit. For other models, the compressor is located indoors.
-
Depth: Standard depth of the unit; can be customized based on server cabinet dimensions.
-
Height: Net height of the unit.
-
Contact Information: If the required data is not listed in the table, please contact the manufacturer.
